87P Compressor
For up to 31″ Tires
P/N 00087 – 60 PSI / 1.26 CFM
87P is a small powerful portable tire inflator with a built-in LED work light, capable of inflating up to 31-inch tires. Simply attach heavy duty battery clamps to your vehicle’s battery and start your engine. Connect the screw-on tire chuck to a tire valve stem before turning the unit on. Tire pressure can be monitored using the gauge incorporated into the top of the unit.
The 87P offers direct power connection to the battery so it can work with any vehicle regardless of the auxiliary power outlet rating.
Please Note: The 87P does not work with Presta bicycle valves.
| FEATURES |
|---|
| – 100 PSI Pressure Gauge |
| – LED Work Light / Power Indicator |
| – Dual Battery Clamps |
| – Solid Brass Twist-on Tire Chuck |
| – 3 pc. Inflation Tips Kit |
| – Deluxe Carry Bag |
| – |
| – |
| – |
| – |
| – |
| – |
| SPECIFICATIONS |
|---|
| – 12-Volt |
| – Permanent Magnetic Motor |
| – Duty Cycle: 20 min. @ 30 PSI |
| – Max. Working Pressure: 60 PSI |
| – Max. Amp Draw: 15 Amps |
| – Ingress Protection Rating: IP53 |
| – Max. Ambient Temp: +158°F |
| – Min. Ambient Temp: -4°F |
| – Dimensions: 9.1″L x 3.1″W x 5.6″H |
| – Net Weight: 4.30 lbs. |
| – Power Cord Length: 10 ft. |
| – Air Hose Length: 8 ft. |
| RECOMMENDED COMPONENTS | |||||
|---|---|---|---|---|---|
| – 6ft. Portable Compressor Air Extension Hose (P/N 00016) | |||||
PERFORMANCE DATA
| PSI | CFM | A | BAR | LPM | A |
|---|---|---|---|---|---|
| 0 | 1.26 | 13 | 0 | 35.7 | 13 |
| 10 | 1.22 | 13 | 1.0 | 33.5 | 13 |
| 20 | 1.13 | 13 | 2.0 | 29.3 | 14 |
| 30 | 1.02 | 14 | 3.0 | 24.8 | 15 |
| 40 | 0.92 | 15 | 4.0 | 20.5 | 13 |
| 50 | 0.80 | 14 | |||
| 60 | 0.71 | 13 |
* Supply Voltage: 13.8 Volts
FILL RATES
| 195/70R14 | Fill Rate |
|---|---|
| 0 to 30 PSI | 2 min. 10 sec. (± 10 sec.) |
| 15 to 30 PSI | 1 min. 10 sec. (± 05 sec.) |
| 225/60R18 | Fill Rate |
| 0 to 30 PSI | 3 min. 00 sec. (± 10 sec.) |
| 15 to 30 PSI | 1 min. 35 sec. (± 05 sec.) |
| 31″ x 10.5″ | Fill Rate |
| 0 to 30 PSI | 4 min. 50 sec. (± 10 sec.) |
| 15 to 30 PSI | 2 min.35 sec. (± 05 sec.) |
MANUAL
DIMENSIONAL DRAWING
