84P Compressor
For up to 31″ Tires
P/N 00084 – 60 PSI / 1.26 CFM
The 84P is exactly the same powerful portable tire inflator as our 85P but with a press-on chuck instead of a twist-on chuck. It has the same power and performance capable of inflating up to 31-inch tires by simply plugging into your cigarette lighter power port (14.5 amps max.). Connect the press-on tire chuck to a tire valve stem before turning the unit on. Tire pressure can be monitored using the gauge incorporated into the top of the unit.
Please Note: Always check your vehicle’s power port rating for maximum amperage before ordering. The 84P does not work with Presta bicycle valves.
| FEATURES |
|---|
| – 100 PSI Pressure Gauge |
| – LED Work Light / Power Indicator |
| – Press-On Chuck |
| – Accessory Power Plug |
| – 3 pc. Inflation Tips Kit |
| – Deluxe Carry Bag |
| – |
| – |
| – |
| – |
| – |
| – |
| SPECIFICATIONS |
|---|
| – 12-Volt |
| – Permanent Magnetic Motor |
| – Duty Cycle: 20 min. @ 30 PSI |
| – Max. Working Pressure: 60 PSI |
| – Max. Amp Draw: 15 Amps |
| – Ingress Protection Rating: IP53 |
| – Max. Ambient Temp: +158°F |
| – Min. Ambient Temp: -4°F |
| – Dimensions: 9.1″L x 3.1″W x 5.6″H |
| – Net Weight: 4.30 lbs. |
| – Power Cord Length: 10 ft. |
| – Air Hose Length: 3 ft. |
| RECOMMENDED COMPONENTS | |||||
|---|---|---|---|---|---|
| – 6ft. Portable Compressor Air Extension Hose (P/N 00016) | |||||
PERFORMANCE DATA
| PSI | CFM | A | BAR | LPM | A |
|---|---|---|---|---|---|
| 0 | 1.26 | 13 | 0 | 35.7 | 13 |
| 10 | 1.22 | 13 | 1.0 | 33.5 | 13 |
| 20 | 1.13 | 13 | 2.0 | 29.3 | 14 |
| 30 | 1.02 | 14 | 3.0 | 24.8 | 15 |
| 40 | 0.92 | 15 | 4.0 | 20.5 | 13 |
| 50 | 0.80 | 14 | |||
| 60 | 0.71 | 13 | * Supply Voltage: 13.8 Volts | ||
FILL RATES
| 195/70R14 | Fill Rate |
|---|---|
| 0 to 30 PSI | 2 min. 10 sec. (±10 sec.) |
| 15 to 30 PSI | 1 min. 10 sec. (±05 sec.) |
| 225/60R18 | Fill Rate |
| 0 to 30 PSI | 3 min. 00 sec. (±10 sec.) |
| 15 to 30 PSI | 1 min. 35 sec. (±05 sec.) |
| 31″ x 10.5″ | Fill Rate |
| 0 to 30 PSI | 4 min. 50 sec. (±15 sec.) |
| 15 to 30 PSI | 2 min. 35 sec. (±05 sec.) |
MANUAL
DIMENSIONAL DRAWING
