Continuous Duty OBA System

NEW!

P/N 20002 – 200 PSI / 2.24 CFM
Tire Inflation IconAir Lockers IconAir Horns Icon

VIAIR’s Continous Duty Onboard Air System is a pre-packaged compressed air solution that provides an industry-leading, 200 PSI rated, 100% duty cycle 485C CE compressor, 2.5 gallon air tank, and all components needed to install a working system capable of inflating tires of virtually any size.



Want to learn more about our Continuous Duty OBA?

Click Here



Additional Info Download:

Manual ‣ Dimensional Drawing ‣ Wiring Diagram ‣

SKU: 20002 Categories: , , Tags: , , , , , , , , , , , , , , , , , , , , ,
FEATURES
– 2.5 Gallon VIAIR Air Tank (200 PSI)
– 485C Stealth Black VIAIR Compressor w/ Thermal Overload Protector
– Digital Tire Inflation Gun with 180 PSI Gauge
– 30ft. Inside Braided Black Coil Hose with Quick Connects
– 1/4” NPT Quick Connect Stud (F)
– 1/4” NPT Quick Connect Coupler (F)
– Dash Panel Gauge with ON/OFF Switch
– Sealed Pressure Switch (165 PSI on, 200 PSI off)
– Reducer 1/8” NPT (F) to 1/4” NPT (M)
– Reducer 3/8” NPT (F) to 1/4” NPT (M)
– 1/4” NPT 250 PSI Safety Valve
– 1/4” NPT Drain Cock
– (3) 1/4” NPT Compression Fittings
– 4” Strip of Grommet Material
– 20ft. 12-Gauge Wire with Inline Fuse Holder
– Electrical Connections
– Accessory Airline
SPECIFICATIONS
– 12-Volt
– Permanent Magnetic Motor
– Duty Cycle: 100% @ 200 PSI
– Max. Working Pressure: 200 PSI
– Max. Air Tank Size: 5.0 Gallon
– Max. Amp Draw: 23 Amps
– Ingress Protection Rating: IP67
– Dimensions: 10.63″L x 4.1″W x 6.44″H
– Net Weight: 11.10 lbs.
–
–
–
–
–
–
–
–
–
RECOMMENDED COMPONENTS
– 0.5 Gallon Tank (P/N 91005)
– 1.0 Gallon Tank (P/N 91010)
– 2.0 Gallon Tank (P/N 91022)
– 2.5 Gallon Tank (P/N 91025)
– 5.0 Gallon Tank (P/N 91050)
– 12V Relay (P/N 93940)
– Pressure Switches (P/N 90100, 90102)
– Pressure Switches with Relay (P/N 90110, 90111)
– Sealed Pressure Switches (P/N 90217, 90223, 90227)


* For 12V Only.
Please Note: Use thread sealant for proper installation. Thread tape is not recommended.
Properly sealed, recommended torque for 1/8” is 10 ~ 11 ft. lbs. Recommended torque for 1/4” and 3/8” is 16 ~ 18 ft. lbs.

PERFORMANCE DATA

PSI CFM A BAR LPM A
0 2.24 12 0 70.0 12
10 1.84 14 1.0 51.0 15
20 1.75 16 2.0 47.0 16
30 1.67 17 3.0 44.0 18
40 1.61 18 4.0 41.0 20
50 1.54 19 5.0 38.0 21
60 1.47 20 6.0 35.0 21
70 1.42 21 7.0 32.0 22
80 1.36 21 8.0 29.0 22
90 1.30 22 9.0 27.0 22
100 1.23 22 10.0 25.0 23
110 1.17 22 11.0 22.0 22
120 1.11 22 12.0 21.0 21
130 1.06 22 13.0 21.0 21
140 1.01 23 13.8 21.0 21
150 0.97 22
160 0.92 22
170 0.88 22
180 0.84 21
190 0.77 21
200 0.73 21

TANK FILL RATES

2.5 Gallon Tank Fill Rate
0 to 200 PSI 4 min. 50 sec. (± 10 sec.)
165 to 200 PSI 1 min. 15 sec. (± 05 sec.)



TIRE FILL RATES

35” x 12.5 Fill Rate
0 to 30 PSI 4 min. 17 sec. (± 10 sec.)
15 to 30 PSI 1 min. 27 sec. (± 05 sec.)
37” x 12.5″ Fill Rate
0 to 30 PSI 5 min. 13 sec. (± 15 sec.)
15 to 30 PSI 1 min. 28 sec. (± 05 sec.)


* Supply Voltage: 13.8 Volts
